| Quantity: | |
|---|---|
| Model | LF200 |
| CYL DIA | 63.5 |
| TOTAL HIGH | 45.5 |
| COMP DIST | 22.5 |
| RING | 1.0*1.0*2.5 |
| PIN DIA | 15 |
| PIN LENGTH | 47.5 |
Crafted exclusively for the LF200 engine, this piston is a specialized high-power compact heavy-duty part that merges premium materials, precision machining, and model-specific design. Built to match the LF200’s optimized specifications—highlighted by its 63.5mm extra-large cylinder diameter, 45.5mm compact total height, and 1.01.02.5mm balanced piston ring set—it delivers seamless fitment, robust power delivery, and long-lasting performance. Whether you’re craving responsive acceleration, hauling medium-to-heavy cargo (up to 880kg), or operating a commercial tricycle in demanding environments, the LF200 piston is the trusted choice for dynamic balance and reliability. Below, we detail its key specifications, design advantages, and versatile applications to help you make an informed purchasing decision.
CYL DIA (Cylinder Diameter): 63.5mm – Extra-large maximizes displacement for exceptional torque output (17.5 N・m @ 6,600 RPM), enabling the engine to handle loads up to 880kg—47% higher than standard 57mm piston models.
TOTAL HIGH (Total Height): 45.5mm – Compact design reduces piston weight by 16% compared to traditional heavy-duty alternatives, minimizing reciprocating mass while maintaining structural rigidity for high-pressure operation.
COMP DIST (Compression Distance): 22.5mm – Optimized compression distance fine-tunes the compression ratio to 9.8:1, enhancing combustion efficiency for both raw power and fuel economy.
Piston Ring Specifications: 1.0*1.0*2.5mm – Balanced triple-ring configuration (two compression rings + one oil control ring) delivers superior sealing (48% reduction in gas leakage vs. standard rings) and reduced oil consumption (28% lower), while minimizing friction for efficient operation.
PIN DIA (Piston Pin Diameter): 15mm – Robust pin diameter ensures stable power transmission to the connecting rod, withstanding extreme torque loads without compromising the piston’s compact design.
PIN LENGTH (Piston Pin Length): 47.5mm – Optimized length distributes stress evenly across the connecting rod, minimizing wear and extending service life in frequent-use and heavy-load scenarios.
High-Power Load Capacity: The high-strength alloy and reinforced structure enable the piston to handle extreme torque and loads up to 880kg, making it ideal for commercial tricycle cargo transport (e.g., construction materials, agricultural supplies) and high-performance motorcycle hauling.
Compact Durability: Resists corrosion, scuffing, and mechanical fatigue while maintaining a lightweight profile, extending the piston’s service life to 90,000km—43% longer than generic high-power pistons.
Stable Heat Management: Efficiently dissipates heat generated by high-compression combustion and frequent stop-start operation, preventing engine overheating and maintaining consistent performance in diverse climates (from arid deserts to humid tropical regions).
Raw Material Testing: Ensures the 2024-T6 aluminum alloy meets aerospace-grade standards for strength, heat resistance, and torque tolerance.
Dimensional Accuracy Checks: Verifies critical dimensions (CYL DIA, COMP DIST, ring groove width) using laser interferometry to match the LF200’s exact tolerances—with special focus on piston ring compatibility and compression seal integrity.
Power & Load Testing: Simulates the LF200’s operating conditions (variable RPM, maximum load) to assess torque output, fuel economy, and compression retention under stress.
Sealing & Wear Tests: Validates the balanced piston ring’s sealing capability and the piston’s wear resistance over 18,000 simulated kilometers of high-performance, heavy-load operation.
Structural Integrity Testing: Ensures the compact design withstands 16,000+ load cycles without deformation or premature failure.
